For a variety of card sizes, this adaptable business card cutter provides accurate, automatic cutting without the need to change the slitter unit. The paper thicknesses it can handle range from 64gsm to 350gsm, and the sizes it can handle are 128 x 128 mm to 235 x 330 mm. Its cutting speed of 100 business cards in about 40 seconds guarantees efficiency for production of large quantities. A laser pointer for precise alignment, a diagonal image adjustment system for resolving print deformities, customizable feed settings, and ultrasonic double-feed detection are among of the key features. Ideal for specialized print applications, including the manufacturing of business cards.
Features
- Can cut any card size without replacing the slitter unit
- In addition to the standard memory, can register 10 custom cut patterns in the user memory
- Adjustable feed settings ensure stable paper handling and prevent curl
- Equipped with Ultrasonic double feed detection, paper feed pressure adjustment mechanism, paper detection sensor, paper feed table lift detection sensor, and tilt adjustment mechanism
- Laser Pointer to check cut mark
- Diagonal image adjustment mechanism Corrects print distortion
- Marker check function
Technical Specification
Paper size | Maximum: Width 235mm x Length 330mm Minimum: Width 128mm x Length 128mm |
Paper Thickness | 0.08mm~0.4mm (Basic weight 64gsm~350gsm) |
Cut size | Feed direction: 47mm to 150mm (numerical input on operation panel) |
Cutting speed | 100 business cards / approx. 40 seconds (A4 size, 10-up, no feed gap) |
Paper applicable | Plain paper, high-quality paper, coated paper, inkjet paper, LIMEX |
Maximum paper load | Stacking thickness: 20 mm (100 sheets of paper, thickness 0.2 mm) |
Number of impositions | 2 to 12 pages (number of pages: 1 to 6) |
Paper Feeding Method | Automatic paper feeding |
Cut Mark | Switchable between black and white marks. |
Display Language | Japanese and English |
Display units | mm & inches |
Machine Dimensions | Width: 595mm (with paper feed support plate attached) x Depth: 464mm x Height: 344mm |
Product weight | Approx. 31kg |
power supply | AC100V 50/60Hz 0.7A |
Operating environment | Temperature: 20-30°C Humidity: 50-70% No condensation |
