Q-Drill – Precision Single-Head Drilling Machine
The Q-Drill is a precision-engineered single-head drilling machine, designed to create clean, accurate holes up to 8 mm in diameter.
The Q-Drill combines efficiency and reliability to meet your production needs.
Key Features:
- Dual Guide Rail System: Ensures smooth and stable movement for precise drilling.
- Optimized Transmission Design: Rear-positioned motor for enhanced performance and durability.
- Advanced Hollow Drill Bits: Equipped with high-tech hollow drill bits for superior cutting efficiency.
- Powerful, Vibration-Free Motor: Specially designed motor delivers consistent, vibration-free drilling.
- Continuous Multi-Hole Drilling: Universal stop gauge facilitates efficient, repeatable drilling.
- Integrated Drill Bit Sharpener: Includes a specialized sharpener for quick and easy drill bit regrinding.
Technical specifications:
Max Punching capacity | 450 sheets (75 gsm) |
Hole diameter | 3-8 mm |
Hole quantity | 1 |
Hole distance | Arbitrary (movable plate) |
Margin adjustment | 8 – 40mm |
Working plate size | 480 X 280mm |
Punching method | Electric |
Machine dimension | 480 X 490 X 500mm |
Voltage | 220/110V, 50/60Hz |
Power | 180w |
Net weight/ Gross weight | 28.5/36.5kg |
